Everyone has heard of steel cord conveyor belts more or less. In daily work, joints are needed. Do you know how to connect steel cord conveyor belts? Next, let's take everyone to find out!

There are several commonly used methods for conveyor belt joints, such as mechanical joints, cold-bonded joints, and hot-vulcanized joints. Mechanical joints generally refer to the use of belt buckle joints, which are convenient, quick and economical. Cold bonding joints use cold bonding adhesives for joints, which are efficient and economical, and should have a better joint effect. Thermal vulcanization joints can ensure high joint efficiency, but also very stable, and the joint life is also very long and easy to master.

Install the vulcanizer first, place the lower frame so that the ends are aligned, and the center line of the frame is aligned with the center line of the steel cord conveyor belt. After the glued parts of the steel cord conveyor belt are made according to the process, clamp the two sides of the glued parts with stoppers, and place the vulcanized plate, water pressure plate, and upper heat insulation board in sequence, and then place the frame on the rack , The middle line is aligned with the middle line of the steel cord conveyor belt, install the connecting bolts, and tighten them one by one, and connect the high-pressure water pipe, the wire plug and the pressure pump respectively.

When joining, all the mesh wires with the head should be cut open, and the glue on the surface should be scraped off, the steel wire rope core conveyor belt at the root of the steel wire should be made into a slope with an angle grinder, and the surface of the original steel wire rope core conveyor belt should be removed and roughened , Clean the polished surface. Lay a layer of clean plastic film on the surface of the lower heating plate, and then lay a layer of rubber material to make the rubber material match the inclined surfaces of the joints at both ends. Lap the steel wire and apply the glue to ensure that the glue is evenly applied. Spread the glue so that the glue is consistent with the slopes at both ends, and a layer of plastic film is placed on it to complete the laying of the steel cord conveyor belt joints and the steel wire Of laps.

The above is the joint method of the steel cord conveyor belt. I hope it will be helpful to everyone. Shandong Yihe Rubber Conveyor Belt Co., Ltd. mainly produces four series of steel cord conveyor belts, layered conveyor belts, and PVC/PVG conveyor belts. Welcome to call advisory!
