Use
Used in coal, mining, port, electric power, metallurgy, chemical industry, food, building material industry, etc, on the strength of a long load type transport line.
Varieties
According to the different tensile layer materials are divided into: cotton canvas (CC) conveyor belt, nylon, polyester) (NN by belt conveyor belt (EP).
Cotton canvas (TC) conveyor belt:
A traditional, and is suitable for the short distance the conveyor belt conveying material.
Nylon (NN) by conveyor belt:
Take body good flexibility, strength, impact resistance, high anti-bending sex good, into Groove type of good, use elongation is small, be applicable to the long-distance higher capacity Under the condition of high speed conveying material.
Polyester (EP) conveyor belt:
Belt body high modulus, use small, heat resistance elongation, Apply to high, high speed.
A hierarchical fabric core belt specifications series
Belt type | Fabrictype | (N/mm)Single tabric strength(N/mm) | Cover thickness | Ply | Width range(mm) | |
Tobrubber | Bottomrubber | |||||
Cotton canvas belt | TC-56 | 56 | 3-12 | 300-2200 | ||
Nylon belt | NN100 | 100 | 3.0-12.0 | 0-3 | 2-10 | 300-2200 |
NN150 | 150 | 2-6 | ||||
NN200 | 200 | |||||
NN250 | 250 | |||||
NN300 | 300 | |||||
NN400 | 400 | |||||
EP belt | EP100 | 100 | 3.0-12.0 | 0-3 | 2-10 | 300-2200 |
EP150 | 150 | 2-6 | ||||
EP200 | 200 | |||||
EP250 | 250 | |||||
EP300 | 300 | |||||
EP350 | 350 | |||||
EP400 | 400 | |||||
|  |  |
